YX360
Price 2,400.00 EG
In stock
About this item
YX360 Case and instrument in one body, that brings you the convenience of carrying and store
Total price 2,400.00 EG
Product Features
- Drop shockproof meter
- Null(zero center) meter ±5 / ±25 in DCV
- High resistance up to 200MΩ with low voltage
- Protective body cover
- Capacitance, dB, Li measurement
Specifications
| Type | Value |
|---|---|
| DCV | 0.1（20kΩ/V) 0.25/2.5/10/50（20kΩ/V)/250/1000V（9kΩ/V) |
| DCV (NULL) | ±5/25V（40kΩ/V) |
| ACV | 10/50/250/750（9kΩ/V) |
| DCA | 50μ/2.5m/25m/0.25A |
| Resistance | 2k/20k/200k/2MΩ (x1/x10/x100/x1k) 200MΩ (x100k) |
| Capacitance | 10μF |
| dB | -10dB～+22dB (for 10VAC) ～+62dB |
| Load current (LI) | 0-150m/15m/1.5m/150μ/1.5μA |
| DC high voltage | DC25kV (optional probe “HV-10T” is necessary) |
| hFE | 1000 at x10 range (optional probe “HFE-6T” is necessary) |
| Battery | R6 (IEC) or UM-3 (1.5V)x2 |
| Fuse | Φ5.2x20mm (250V/0.5A) |
| Size/Mass | H159.5×W129×D41.5mm/Approx. 320g |
