Flame module module red board flame sensor module KY-026 applicable

Price 35.00 EG

About this item

4-Pin Interface: Includes VCC (power), GND (ground), DO (digital output), and AO (analog output) for easy integration.
High Sensitivity: Detects flame or light sources with wavelengths between 700nm and 1100nm.
Adjustable Sensitivity: Features a built-in potentiometer to set the detection range.
Digital Output (DO): Normally LOW; goes HIGH when a flame is detected.
Analog Output (AO): Provides a real-time voltage signal that drops when a flame is detected, allowing for precise measurement.
Detection Range: Up to 100 cm (adjustable, depending on flame size).
Detection Angle: Approximately 60 degrees, highly sensitive to flame spectrum.
Operating Voltage: 3.3V – 5V.
Low Power Consumption: Maximum current draw <7mA.
LED Indicators: Includes a power LED and a signal detection LED for easy status monitoring.
Comparator Chip: Uses LM393 for stable and reliable readings.
Driving Ability: >15mA, ensuring compatibility with most microcontroller inputs.
Compact Size: PCB dimensions approximately 3.2cm x 1.4cm.
Fast Response Time: Provides quick and accurate detection.

Fire Detection Systems: Ideal for early warning systems in homes, industries, or vehicles.
Flame Alarms and Safety Equipment: Can be used in safety systems to detect flames and trigger alarms or shut off devices.
Flame-Detecting Robots: Useful in robotics for fire-fighting or fire-detection applications.
Gas Lighters and Ignition Systems: Can detect flames for safety in gas-based systems.
Safety Systems: Can be integrated into devices to automatically cut off power or trigger alerts in case of fire.
Monitoring Systems: Useful for continuous fire prevention monitoring in warehouses, labs, or other environments.
Educational Projects: Great for prototyping and learning about sensor integration and fire detection.
General IR Detection: Can be used in projects requiring detection of IR light sources beyond just flames.
