HB808C Digital Stepper Motor Driver 24-80VDC
Price 2,900.00 EG
In stock
About this item
The HB808C Digital Stepper Motor Driver is a versatile and high-performance solution designed for precise motion control applications. Operating within a wide voltage range of 24VDC to 80VDC, it delivers continuous output currents up to 8.0A, with peak currents reaching 13A, ensuring robust performance for demanding tasks. Utilizing advanced Field-Oriented Control (FOC) and Space Vector Pulse Width Modulation (SVPWM) technologies, the HB808C offers closed-loop control that combines the benefits of stepper and servo systems. This integration results in enhanced accuracy, reduced heat generation, and improved motor efficiency.
Total price 2,900.00 EG
Product Features
- Wide input voltage range of 24VDC to 80VDC.
- Continuous output current up to 8.0A; peak current up to 13A.
- Supports position, speed, and torque control modes.
- Accepts differential and single-ended pulse/direction commands.
- Maximum pulse frequency of 500kHz.
- Compatible with NEMA 23-86 hybrid stepper motors with encoders.
- RS232 serial port for configuration and monitoring.
- Adjustable resolution from 400 to 25600 pulses per revolution.
- Built-in protection against over-voltage, under-voltage, over-current, and tracking errors.
- Utilizes FOC and SVPWM technologies for efficient closed-loop control.
Product Applications
- CNC milling machines.
- 3D printers.
- Robotics and automation systems.
- Laser engraving machines.
- Medical equipment.
- Textile machinery.
- Packaging machinery.
- Stage lighting systems.
