UTS3032T+
Price 74,907.00 EG
In stock
About this item
The UTS3000T+ series spectrum analyzer can measure frequencies up to 8.4GHz. It is a spectrum analyzer with wide frequency band coverage and superior performance. The series adopts mature all digital IF technology. It provides a variety of analysis functions, and up to 40,001 scanning points , providing better help for your frequency domain analysis. This series of spectrum adopts a 10.1 inch large touch screen, which will bring you a better use experience. The UTS3000T+ series can be applied to functional/terminal/quality inspection tests in the electronics manufacturing industry, as well as wireless communication measurement, RF microwave courses, electromagnetic compatibility pre-scan, semiconductor measurement and many other application scenarios.
Total price 74,907.00 EG
Product Features
- Frequency Measurement Range:9 kHz to 3.2 GHz
- Displayed Average Noise Level (DANL): As low as -161 dBm (Typical)
- Phase Noise: < -98 dBc/Hz (Offset 10 kHz, Typical)
- Full Amplitude Accuracy: < 0.7 dB
- Sweep Points: Up to 10,001
- Minimum Resolution Bandwidth (RBW): 1 Hz
- Advanced Function: One key measurement support (Optional)
- EMI Pre-compliance Analysis Function: Supported (Optional)
- Analog Demodulation Analysis: Supported (Optional)
- Tracking Source Output: Supported
- Display: 10.1-inch 1280 × 800 HD Capacitive Touchscreen
- SCPI Support: Standard commands for programmable instruments, USB/LAN interface
