UDP3305S-E 4Ch Advanced-Series Programmable Linear DC Power Supply
Price Updated soon
In stock
About this item
The UNI-Trend UDP3305S-E High-Performance programmable linear DC power supply is a diverse and cost-effective unit for teaching, scientific research, and measuring in the industrial field.
Product Features
- Channels 4Ch
- Output Voltage CH1/CH2:0~30V CH3:0~6V CH4:5V
- Output Current CH1/CH2:0~5A CH3:0~3A CH4:2A
- Total Power 328W
- Max V Resolution 10mV
- Max A Resolution 1mA
- Connectivity USB Device, RS-232, LAN, USB host, Digital I/O
- Setting Accuracy
- <0.3%+20mV <0.2%+5mA
- Type
- linear DC power supply
- Warranty 3 years
- Shipping Dimensions 355×240×168(mm)
- Shipping Weight 10.2Kg
- Documents English download guide, multi-language safety manual, calibration report (COC)
- Included Accessories Power cord, USB2.0 printing cable
